Mean Well Non-Dimmable Constant Current IP42 APC-8 8W 16-32V LED Driver 250mA
Quick Find: 51329
Part No: APC-8-250
FREE Shipping
On orders over £65.00
On orders over £65.00
Out of stock until 7th April, 2023
You are still able to preorder this product but delivery will be after this date.
You are still able to preorder this product but delivery will be after this date.
Price
£13.61
Inc. VAT £16.33
RRP £15.84
14% Off
Save a total of £2.23
Save a total of £2.23
£13.61
Inc. VAT £16.33
Inc. VAT £16.33
Saving 14% (£2.23) on RRP: £15.84
Quick Find: 51329
Part No: APC-8-250
Control Gear Technology
LED
Control Gear Type
LED Driver
Current Output
250mA
Dimming?
Non-Dimmable
Height
22 mm
Input Voltage
90-264 V
Length
60 mm
Manufacturer
Mean Well
Material
Plastic
Output Voltage (LED Driver)
32 V
Type
Control Gear
Voltage
16-32 Volt
Wattage
10 W
Width
30 mm
Mean Well Non-Dimmable Constant Current IP42 APC-8 8W 16-32V LED Driver 250mA from Mean Well
Model: APC-8-250
Technical Specifications
| Control Gear Type | LED Driver |
|---|---|
| Wattage | 10 W |
| Manufacturer | Mean Well |
| Dimming? | Non-Dimmable |
| Height | 22 mm |
| Input Voltage | 90-264 V |
| Length | 60 mm |
| Type | Control Gear |
| Voltage | 16-32 Volt |
| Material | Plastic |
| IP Rating | IP40 |
| Current Output | 250mA |
| Warranty | 5 Years |
| Frequency Range | 47~63Hz |
| AC Inrush Current (max.) | Cold start, 70A at 230VAC |
| Width | 30 mm |
| Safety Standards | UL8750, GB19510.14, GB19510.1 approved; Design refer to EN60950-1, EN61347-1, EN61347-2-13 (LVD) |
| AC Current | 0.15/230VAC; 0.3A/115VAC |
| Efficiency | 82.5% |
| Output Voltage (LED Driver) | 32 V |
| Control Gear Technology | LED |
Alternative Stock Identifier Part Codes
Components
For Mean Well Non-Dimmable Constant Current IP42 APC-8 8W 16-32V LED Driver 250mA
Downloads
| Datasheet Mean Well Constant Current IP42 APC-8 10W 32V LED Driver |
