How Do I Know Which LED Driver to Buy?

It is complicated to select the ideal LED driver if you know the basics. Consider the driver as the lifeblood of your LED system; it delivers the right power to your light source to keep it running efficiently. Select the wrong one, and you may find yourself with flickering, reduced light output, or a strip that's burnt out.

Start with the power requirement of the LED. Every strip or fixture has three important specs: voltage (12V or 24V), wattage per meter (in watts), and current (in milliamps). Your driver needs to have the same voltage as the strip. When you're using a 12-volt DC strip, you'll need a 12V driver. Use a 24V driver to power a 24V strip. This is very important, or you will damage your LED strip.

12V or 24V: Which is better?

Both are okay, but 24V strips are best for larger projects. They can tolerate longer runs with less voltage drop, so light output. is uniform throughout the entire run. 12V strips are okay in small spaces or as accent lights. For larger jobs, 24V is preferable.

Second, choose a constant voltage (CV) or constant current (CC) driver.

LED strips and most household LED designs use constant voltage drivers. They output a set amount of voltage, and the strip's internal resistors will control the current. High-power LEDs or modules where the current needs to be tightly controlled, industrial lighting or one high-brightness LED constant current drivers needs to be used.

Constant voltage for strip and ambient lighting, constant current for specialty or high-power LEDs.

What’s the best LED driver brand or type?

Established brands like Mean Well, Philips, Tridonic, and Osram are famous for the reliability and stability of their output. Use surge-protected drivers, dimming feature (if required), and safety certifications like CE or UL. It's worth buying quality; a cheap driver will cost a few pounds less, but could within three or four months.

How to test an LED driver to determine if it operates?

If your LEDs flash, refuse to illuminate, the problem could lie in the driver. Test it with a multimeter. Test it at DC voltage and between output pins; it should be equal to the rated voltage (12V, 24V, etc.). If it's below or unstable, the driver is faulty. Test it for heat build-up, buzzing, or burning odour too — all indications it's time to replace it.

What wattage driver do you need?

First, work out the total wattage of your system. For example, if you have an 8-meter run of LED strip that is rated at 10 watts per meter.

8 x 10watts is a total of 80 watts.

A brief note before buying: Always choose a driver of at least 10–20% higher watt capacity than your load on the LEDs. If your strip is 80W loaded, buy a 100W driver. That's your buffer space, so the driver will be longer-lasting and cooler-running.

In short:

1. Determine your LED's voltage (12V or 24V)

2. Choose constant voltage for strings of LEDs, constant current for individual LEDs.

3. Use established brands that already have protection.

4. Give yourself a bit of headroom when selecting the wattage.

5. Test it with a multimeter if something does go wrong.

Now that you're familiar with these basics, choosing the right LED driver will be second nature, and your lights will thank you.
