Robus PROTON Black Multi-Directional 180 Degree PIR IP54

This is a Product image
Quick Find: 66580
Part No: RPR180PIR-04
FREE Shipping
On orders over £75.00
IN Stock
Available for delivery

Price
£17.63

Inc. VAT
£21.16

RRP
£38.12

On Sale
54% Off
Save a total of £20.49
£17.63
Inc. VAT £21.16
On Sale
Saving 54% (£20.49) on RRP: £38.12
Quick Find: 66580
Part No: RPR180PIR-04

Accessory Type
Sensor

Finish
Black

Height
51 mm

IP Rating
IP65

Length
118 mm

Manufacturer
Robus

Type
Accessory

Voltage
220-240 Volt

Width
80 mm

Robus PROTON Black Multi-Directional 180 Degree PIR IP54 from Robus

Model: RPR180PIR-04

Suitable for outdoor applications, it has a manual over ride with automatic reset after 8 hours with large terminals that accept 2 x 1.5mm2 conductors in each terminal and the facility for loop in loop out. Passive infra red ensures light is switched on when this Robus sensor detects movement of heat and is switched off when area is vacated, which minimises false/unwanted triggering. Earth terminal included and 3 wire capacity means multiple sensors can be wired in parallel. High load contact rating, allows numerous fittings to be switched with no minimum load requirements. Maximum loading: - 1200W Incandescent - 300W Fluorescent - 300W LED. Adjustable time delay of 10sec to 15min. Adjustable lux settings 3lx to 2000lx. Max detection area of 12m diameter at 2.5m. Complete with accessory shield to reduce detection angle. Corner mounting bracket available as accessory - code: RPRBRK-01. Not for sale in Germany, France, Belgium, Netherlands, Switzerland, Luxembourg and Italy.

Technical Specifications

Accessory Type Sensor
Manufacturer Robus
Height 51 mm
Length 118 mm
Type Accessory
Finish Black
Voltage 220-240 Volt
IP Rating IP65
Warranty 5 Years
Width 80 mm
